Safari Wheelchair
Combi Accessories
Combi Accessories
Combi Accessories

SAFARI

Specification:

Specifications
SAFARI
Drive Wheels size
200 mm (8")
Caster Wheels size
178 mm (7")
Overall Length
870 mm (34.3")
Overall Width
600 mm (23.6")
Height
840 mm (33")
Standard Seat Width
410 mm (16.2")
Standard Seat Depth
400 mm (15.8")
Back rest height
370 mm (14.6")
Back rest angles
12 degree
Weight Capacity
150 Kg (330 lbs)
Total Weight With Batteries (SLA)
36.5 Kg (80 lbs)
Weight of Motor mount complete
16.7 Kg (36.8 lbs)
Heaviest Piece
16.7 Kg (36.8 lbs)
Breaks Down Into
2 pieces
Weight of seat (included armrest)
10.6 kg (23.4 lbs)
Maximum Speed SLA battery
6.2 kph (3.9 mph)
Turning Radius
700 mm (27.6")
Ground Clearance
{105 (4.1")on foot board} 70mm (2.76")
Battery (SLA/Lithium)
24V15ah
Weight of battery (SLA/Lithium)
9.2Kg/4Kg (20 lbs / 9 lbs)
Slope Grade Ability
9 degree
Travel Distance SLA/ Lithium
Up to 10/16.5 km (Up to 6.2 / 10.2 mile)
Battery Charger SLA
2A Off Board
Battery Charger Lithium
4A Off Board
Armrest height
200 (7.9")
Brake
Dynamic Braking and Electromagnetic Brake
